AST 1019-P % Oxygen Analyzer

Advanced Sensor Technology

AST-1019-P % oxygen analyzer can be used to measure oxygen concentration in inert gas as well as gaseous hydrocarbon stream. User selectable any range from 0-25%, with signal output locked on the desired range, the lowest range available is 0-1% with very high display resolution – 3 digits after the decimal point.
AST-1019-P % oxygen analyzer provides two user selectable oxygen alarms with latching or non-latching feature, user selectable digital filter for optimum signal to noise ratio with acceptable system response time.
Expected sensor life of  the standard AST-222 % O2 sensor is 60 months in air under ambient temperature and pressure. Standard sensor is suitable for measuring oxygen in inert and gaseous hydrocarbons. AST-222Z , with 30 months life in air, is recommended for measuring oxygen in gas streams containing any level of CO2 gas.



  •
    • Proprietary electrolyte formulation and the geometry of the anode extends sensor life
    • Recovery from air to 0.1% in under 30 seconds
    • Extended operating temperature range -10°C (-4°F) Z-Series sensor compatibility with gas streams containing any level of CO2 gas.
    • Fast sensor response and recovery, no routine sensor maintenance

    Key Analyzer Features

    • User selectable range from 0-1% to 0-25%
    • Analog output locking on selected range
    • Isolated 4-20mA and 0-1 VDC Full Scale signal output
    • Two user selectable O2 alarm relays
    • Sensor fail alarm

    Power Requirement

    100-240 VAC Universal AC/DC 5V Power Adaptor. Can be Powered via USB cable fitted with recommended jack
